Specifications
*spec applies to all sizes unless otherwise noted

Frameset
Frame OCLV Mountain Carbon main frame & stays, internal storage, tapered head tube, Knock Block 2.0, Control Freak internal routing, Carbon Armor, shuttle guard, threaded BB, ISCG 05, 34.9mm seat tube, magnesium rocker link, Mino Link, ABP, Boost148, 160mm travel
Fork RockShox ZEB Ultimate, DebonAir spring, Charger 2.1 RC2 damper, tapered steerer, 44mm offset, Boost110, 15mm Maxle Stealth, 170mm travel
Shock NEW RockShox Super Deluxe Ultimate, DebonAir spring, Thru Shaft 3-position damper, 230x62.5mm
Max compatible fork travel 180mm (596mm axle-to-crown)
Wheels
Wheel front NEW Bontrager Line Elite 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle
Wheel rear Bontrager Line Elite 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost148, 12mm thru axle
Hub front Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15mm thru axle
Hub rear Bontrager alloy, sealed bearing, 6-bolt, 108T Rapid Drive, SRAM XD driver, Boost148, 12mm thru axle
Skewer rear Bontrager Switch thru axle, removable lever
*Tire Size: S , M , ML , L , XL
Bontrager SE4 Team Issue, Tubeless Ready, Core Strength sidewall, aramid bead, 60 tpi, 29x2.40''
Size: S , M , ML , L , XL
Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewall, aramid bead, 60 tpi, 29x2.60''
*Tire part Size: S , M , ML , L , XL
Bontrager TLR sealant, 6oz
Size: S , M , ML , L , XL
Bontrager TLR valve, 50mm
Rim strip Bontrager TLR
Max tire size Frame: 29x2.50" Fork: See manufacturer
Drivetrain
Shifter SRAM X01 Eagle, 12 speed
Rear derailleur SRAM X01 Eagle
*Crank Size: S
SRAM X01 Eagle, DUB, 30T alloy ring, Boost (55mm chainline), 170mm length
Size: M , ML , L , XL
SRAM X01 Eagle, DUB, 30T alloy ring, Boost (55mm chainline), 175mm length
*Bottom bracket Size: S , M , ML , L , XL
SRAM DUB MTB Wide, 73mm, BSA threaded
Size: S , M , ML , L , XL
SRAM DUB, 73mm, BSA threaded
Cassette SRAM Eagle XG-1275, 10-52, 12 speed
Chain SRAM GX Eagle, 12 speed
Max chainring size Max: 34T, Min 28T
Components
Saddle Bontrager Arvada, austenite rails, 138mm width
*Seatpost Size: S
Bontrager Line Elite Dropper, 100mm travel, MaxFlow, internal routing, 34.9mm, 345mm length
Size: M , ML
Bontrager Line Elite Dropper, 150mm travel, MaxFlow, internal routing, 34.9mm, 440mm length
Size: L
Bontrager Line Elite Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 485mm length
Size: XL
Bontrager Line Elite Dropper, 200mm travel, MaxFlow, internal routing, 34.9mm, 550mm length
Handlebar Bontrager Line Pro, OCLV Carbon, 35mm, 27.5mm rise, 820mm width
Grips Bontrager XR Trail Pro, alloy lock-on
Stem Bontrager Line Pro, 35mm, Knock Block, Blendr compatible, 0 degree, 35mm length
Headset Knock Block 2.0 Integrated, 72-degree radius (includes infinite-radius chip), sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom
Brake SRAM Code RSC 4-piston hydraulic disc
*Brake rotor Size: S , M , ML , L , XL
SRAM CenterLine, 6-bolt, round edge, 180mm
Size: S , M , ML , L , XL
SRAM CenterLine, 6-bolt, round edge, 200mm
Accessories
Bag Bontrager BITS Internal Frame Storage Bag
Weight
Weight M - 14.12 kg / 31.14 lbs (with TLR sealant, no tubes)
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
