Frameset
Frame 800 Series OCLV Carbon, KVF (Kammtail Virtual Foil) tube shape, adjustable top tube IsoSpeed, invisible cable routing, 3S aero chain keeper, T47 BB, DuoTrap S compatible, flat mount disc, 142x12mm thru axle
Fork Madone KVF full carbon, tapered carbon steerer, invisible cable routing, flat mount disc, carbon dropouts, 12x100mm thru axle
Frame fit H1.5 Race
Wheels
Wheel front Bontrager Aeolus XXX 4, OCLV Carbon, Tubeless Ready, 21mm rim width, 47mm rim depth, 100x12mm thru axle
Wheel rear Bontrager Aeolus XXX 4, OCLV Carbon, Tubeless Ready, 21mm rim width, 47mm rim depth, 142x12mm thru axle
Skewer front Bontrager Switch thru axle, removable lever
Skewer rear Bontrager Switch thru axle, removable lever
Tire Bontrager R4 320 Handmade Clincher, Hard-Case Lite, 320 tpi, 700x25c
Rim strip Bontrager Aeolus XXX rim strip
Max tire size 28c
Drivetrain
Shifter SRAM RED eTap AXS, 12 speed
Front derailleur SRAM RED eTap AXS, braze-on
Rear derailleur SRAM RED eTap AXS, Orbit chain management, 33T max cog
*Crank Size: 47
SRAM RED AXS Power Meter, 48/35, DUB spindle, 165mm length
Size: 50, 52
SRAM RED AXS Power Meter, 48/35, DUB spindle, 170mm length
Size: 54, 56
SRAM RED AXS Power Meter, 48/35, DUB spindle, 172.5mm length
Size: 58, 60, 62
SRAM RED AXS Power Meter, 48/35, DUB spindle, 175mm length
Bottom bracket SRAM DUB, T47 threaded, internal bearing
Cassette SRAM RED XG-1290, 10-33, 12 speed
Chain SRAM RED D1, 12 speed
Components
Saddle Bontrager Aeolus Pro, carbon rails, 145mm width
*Seatpost Size: 47, 50, 52, 54, 56
Madone aero carbon internal seatmast cap, integrated light mount, 25mm offset, short length
Size: 58, 60, 62
Madone aero carbon internal seatmast cap, integrated light mount, 25mm offset, tall length
*Handlebar Size: 47
Trek Madone adjustable aero VR-CF, OCLV Carbon, invisible cable routing, 93mm reach, 123mm drop, 38cm width
Size: 50, 52
Trek Madone adjustable aero VR-CF, OCLV Carbon, invisible cable routing, 93mm reach, 123mm drop, 40cm width
Size: 54, 56
Trek Madone adjustable aero VR-CF, OCLV Carbon, invisible cable routing, 93mm reach, 123mm drop, 42cm width
Size: 58, 60, 62
Trek Madone adjustable aero VR-CF, OCLV Carbon, invisible cable routing, 93mm reach, 123mm drop, 44cm width
Handlebar tape Bontrager Supertack Perf tape
*Stem Size: 47, 50, 52, 54
Trek Madone aero, invisible cable routing, 7 degree, 90mm length
Size: 56, 58
Trek Madone aero, invisible cable routing, 7 degree, 100mm length
Size: 60, 62
Trek Madone aero, invisible cable routing, 7 degree, 110mm length
Brake SRAM Red eTap AXS hydraulic disc, flat mount
Brake rotor SRAM CenterLine X, centerlock, round edge, 160mm
Accessories
Electronics SRAM Etap Battery Pack w/ Charger
Weight
Weight 56 - 7.86 kg / 17.32 lbs
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Prices shown are manufacturer's suggested retail prices.
Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
Sizing & fit
The charts below show our recommended sizes based on height, but there are some other factors, like arm and leg length, that determine a great fit. That’s why you’ll see some overlap in our recommendations. Not every rider who’s 5´8˝, for example, will fit on the same size bike. The best way to find your perfect fit is to consult the experts at your local retailer.
