Printing Method
Printing Technology 12-color 24.0″ inkjet printer with non-firing nozzle detection & compensation
Maximum Resolution 2400 x 1200 dpi
Minimum Ink Droplet Size 4.0 pl
Ink Type Pigment-based
Ink Palette Cyan, Photo Cyan, Magenta, Photo Magenta, Yellow, Black, Matte Black, Red, Green, Blue, Gray, Photo Gray
Ink Cartridge Configuration 12 cartridges, 6 cartridges per printhead
Number of Nozzles Per Color: 2,560 nozzles
Total: 30,720 nozzles
Nozzle Pitch 1200 dpi
Printer Language GARO
Paper Handling
Paper-Feed Method Top-loading manual feed, front-loading manual feed
Maximum Printable Area 24.0″ x 59.0′ (60.96 cm x 18.0 m)
Paper Sizes Standard: Letter, Legal, Ledger, Super B, 10.0 x 12.0″, 10.0 x 15.0″, 12.0 x 16.0″, 13.0 x 22.0″, 14.0 x 17.0″, 18.0 x 22.0″, 16.0 x 20.0″, 20.0 x 24.0″, 20.0 x 30.0″, 300 x 900 mm, A1, A2, A2+, A3, A3+, A4, B2, B3, B4, JIS B2, JIS B3, JIS B4, ANSI D, ANSI C, ARCH A, ARCH B, ARCH C, ARCH D, DIN C2, DIN C3. DIN C4
Custom – Sheet (Top Load): 8.0 x 11.0 to 24.0 x 63.0″ (20.32 x 27.94 to 60.96 x 160.0 cm)
Custom – Sheet (Front Load): 8.0 x 16.5 to 24.0 x 36.0″ (20.32 x 42.0 to 60.96 x 91.44 cm)
Roll: 8.0 x 8.0″ to 24.0″ x 59.0′ (20.32 x 20.32 cm to 60.96 cm x 18.0 m)
Borderless Printing Width A1, A2, A2+, A3+, B2, B4, 10.0″ (25.4 cm), 14.0″ (35.56 cm), 16.0″ (40.64 cm), 17.0″ (43.18 cm), 24.0″ (60.96 cm)
Maximum Roll Print Length 59.0′ (18.0 m)
Paper Types Plain, coated, photo, proofing, art, sign/CAD
Media Thickness Sheet (Top-Load): 3.2 to 31.4 mil (0.07 to 0.8 mm)
Sheet (Front-Load): 19.6 to 59.0 mil (0.5 to 1.5 mm)
Roll: 3.2 to 31.4 mil (0.07 to 0.8 mm)
Cutter Automatic/Manual
Maximum Media Roll Diameter 5.9″ (150 mm)
Core Size 2.0 or 3.0″ (5.08 or 7.62 cm)
Connectivity
Interface USB: Hi-Speed USB 2.0
Network: 10/100/1000 Base-T/TX Ethernet
OS Compatibility Windows: Windows 7 (32/64-bit), Vista (32/64-bit), XP (32/64-bit), Server 2003 (32/64-bit), Server 2008 (32/64-bit)
Mac: OS X 10.5.8 to 10.7x
Solaris 9
Red Hat 9
Internal Memory 384 MB
Hard Disk Capacity 250 GB
Physical
Control Panel LCD
LEDs: Cut Sheet, Roll Media, Message, Data
Buttons: Power, Stop, Navigate, OK, Back, Menu, Cut, Feed, Load, 4 directional arrows
Power Requirements 100 to 240 V AC (50 to 60 Hz)
Power Consumption Maximum: 100 W
Standby: ≤ 6.0 W
Power Off: ≤ 0.5 W
Acoustic Noise Sound Pressure (Printing): ≤ 47 dB(A)
Sound Pressure (Standby): ≤ 35 dB(A)
Sound Power (Printing): ≤ 6.4 B(A)
Certifications International Energy Star Program, Eco Mark (Japan), Law on Promoting Green Purchasing (Japan), GPN, RoHS (Europe/China), Eco Declaration (Europe), WEEE (Europe/India), U.S. Presidential Directives, ErP Directive
Temperature / Humidity Operating Temperature: 59 to 86 °F (15 to 30 °C)
Operating Humidity: 10 to 80%
Dimensions (WxDxH) 48.3 x 34.3 x 39.4″ (122.68 x 87.12 x 100.08 cm)
Weight 154 lb (69.85 kg) including stand
Packaging Info
Package Weight 154.0 lb
Box Dimensions (LxWxH) 53.0 x 37.0 x 36.5″
