Advanced PrecisionCore MicroTFP Print Head
10-channel, piezo inkjet print head
Ink Type Epson UltraChrome PRO pigment inks, 10-ink, 9-color
Ink Configuration: C, LC, VM, VLM, Y, LGY, GY, DGY, PK, MK
Printer is designed for use with Epson cartridges only,
not third-party cartridges or ink.
Printer Nozzle Configuration Color and Monochrome; 800 nozzles x 10 channels
Enhanced Variable Droplet Technology as small as 3.5 picoliters
Print Resolutions 2400 x 1200 dpi; 1200 x 1200 dpi; 1200 x 600 dpi;
600 x 600 dpi; 600 x 300 dpi
Available resolutions vary by media type
Dimensions (LxWxH) 95cm x 39cm x 46cm
Printer Weight 377 lbs / 171kg
Operating Systems Supported Apple® OS X® 10.11x, 10.10x, 10.9x, 10.8x and 10.7x
Microsoft® Windows® 10, 8.1, 7 (32-bit, 64-bit)
Printer Interfaces & Language USB 2.0 (1 port)
1000Base-T Ethernet (1 port)
Printer Language & Drivers Epson Professional Photographic Drivers standard; optional
internal Adobe® Postscript® 3™ print server
Acoustic Noise Level Sound Pressure Level: Less than 51.1 dB(A)
Sound Power Level: approx. 65.3 dB(A)
Limited Warranty and Service Standard one-year on-site next business day service with
toll-free phone support Monday thru Friday.
Optional Epson SureColor P-Series Extended service plans.
available for purchase.
Epson Intelligent Ink Cartridge
Initial cartridge fill volume 110 ml x 10 total colors (used for initial fill at setup)
Cartridge fill volume 700 ml each x 10 colors total
Ink cartridge shelf life (recommended) 2 years from printed production date or 6 months after open
Print Permanence
Color Up to 200 years
Black-and-White Up to 400 years
Roll Media Handling
Single top loading roll 64″ wide
2″ or 3″ core diameter User adjustable media adapters
Roll cutting High-speed internal rotary cutter; Automatic or manual
Minimum auto cut length 11.0″ plus top and bottom margin (11.24″ minimum)
Top/ bottom margins (mm) Normal: setting varies based on media selection
Optional fixed: 3/3, 15/15, 35/15, 45/15
Left and right margins 3mm each side; 0.24″ total, or 0″ at BorderFree® sizes
Roll paper remaining Printable barcode tracking system
Optional Take-up reel Auto forward and backward; light based media sensor
Sheet Media Handling
Single sheet, top loading Up to 64″ wide
Sheet loading Top-loading if less than 0.5mm thick
Media Thickness 0.8mm to 1.5mm
Top/bottom margins 3mm/15mm (0.12″/0.59″)
Top/bottom margins with centering on 15mm/15mm
Left and right margins 3mm each side; 6mm or 0.24″
Printer Speeds 16″ x 20″ prints from 1:47 to 3:17 Production is 2:09
20″ x 30″ prints from 2:55 to 5:33 Production is 3:40
40″ x 60″ prints from 8:33 to 16:30 Production is 10:52
Printable Area
Minimum paper width 13″
Maximum paper width 64″
Minimum cut-sheet size 8.5″ x 11″
Minimum recommended cut-sheet 13″ x 19″
Maximum printable cut-sheet length 80″
Maximum printable roll length 590.55″
Line accuracy +/-0.2% of specified length (+/- 0.26mm minimum
BorderFree® Printing Left and right borderless “bleed” printing for the following roll widths
10″, 11.8″, 13″, 16″, 17″, 20″, 23″, 24″, 28.86″, 29″, 33.11″, 36″, 40.55″,
44″, 50″, 54″, 60″
Electrical Requirements
Printer
Voltage AC 110-240V
Frequency 50-60 Hz
Current 5A
Power Consumption
Printer
Printing Approx. 95W
Sleep Approx. 2.8W (100 BaseT Ethernet in Standby)
Power Off Less than 0.5W
Fully ENERGY STAR Complaint
Environmental Characteristics
Temperature Operating 50° to 95°F (10° to 35°C)
Operating Recommended
Storage 65° to 75°F (18° to 24°C)
-4° to 104°F (-20° to 40°C)
Relative Humidity
Operating 20 to 80% (no condensation)
Operating Recommended 40 to 60% (no condensation)
Recommended Storage 5 to 85% (no condensation)
