Printing Method
Print Technology FINE (Full-Photolithography Inkjet Nozzle Engineering)
Print Resolution 2400 x 1200 dpi
Print Speed Arch D 24 x 36″ (61.0 x 91.4 cm): 21 seconds in Economy Mode
Arch E 33.1 x 46.8″ (84.1 x 118.9 cm): 41 seconds in Economy Mode
Print Head PF-04
Ink Droplet Size 4 pl
Line Accuracy ±0.1% or less
Minimum Line Weight 0.79 mil (0.02 mm)
Number of Nozzles Matte Black: 5,120 nozzles
Other Colors: 2,560 nozzles per color
Nozzle Pitch 1200 dpi x two rows
Printhead Swath 1.07″ (27.2 mm)
Ink Types Dye: Cyan (C), Magenta (M), Yellow (Y), Black (K)
Pigment: Matte Black (MBK)
Compatible Ink Tanks PFI-107 (130 ml): C, M, Y, BK, MBK
PFI-207 (300 ml): C, M, Y, BK, MBK
Ink Tank Capacity Starter: 130 ml (MBK), 90 ml (C, M, Y, BK)
Replacement: 130 ml (PFI-107) or 300 ml (PFI-207)
Ink Supply Method Tubing system with sub-ink-tanks for continuous ink supply
Nozzle Recovery System Non-firing nozzle detection and compensation
Media Handling
Paper Handling Roll Feed: One roll, top-loading, front output
Cut Sheet: One sheet, top-loading front output
Media Width Roll Feed: 10-36″ (254-914 mm)
Cut Sheet: 8-36″ (203-914 mm)
Maximum Print Length Roll Feed: 59′ (18 m)
Cut Sheet: 63″ (1.6 m)
Margins Roll Feed, All Sides: 0.12″ (3 mm) or 0″ (0 mm) for borderless
Cut Sheet, Leading, Sides (Left and Right): 0.12″ (3 mm)
Cut Sheet, Trailing: 0.91″ (23 mm)
Borderless Printing Width Roll Media: 10″ (25.4 cm), B4, A3, 14″ (35.6 cm), A2, 17″ (43.2 cm), B2, A1, 24″ (61.0 cm), B1, A0, 36″ (91.4 cm)
Media Cutter Durable dual-blade rotary cutter
Media Thickness 2.8-31.4 mil (0.07-0.80 mm)
Core Sizes 2″ (5.1 cm) and 3″ (7.6 cm)
Maximum Media Roll Diameter 5.9″ (150 mm)
Output Flat stacker, basket
Output Capacity 20 sheets with stackable configuration
Connectivity
Interfaces USB 2.0
10/100/1000Base-T/TX
Controller L-COA Processor
Memory 256 MB
Internal Hard Drive None
Mail Server None
Compatible Operating Systems Windows XP (32-bit), Server 2003 (32/64-bit), Server 2008 (32/64-bit), Server 2012 (64-bit), Vista (32/64-bit), 7 (32/64-bit), 8 (32/64-bit)
Macintosh OS X 10.6.8-10.9.x
Print Languages GARO (Canon proprietary), HP-GL/2, HP RTL
Protocols TCP/IP (IPv4/IPv6), IPX/SPX, AppleTalk, SNMP (Canon MIB supported), HTTP
Physical
Acoustic Noise Operation: 48 dB
Standby: 35 dB or less
Acoustic Power: 65 dB
Power Requirements 100-240 VAC, 50-60 Hz
Power Consumption Maximum: 140 W or less
Standby: 5 W or less
Power Off: 1 W or less (Executive Order Compliant)
Certifications Electrical Safety Regulations: TUV (USA), cTUV (USA), TUV.S mark, CB certification (others)
Electromagnetic Interface Regulations: FCC Class B (USA), IC Class B (Canada)
Environmental: ENERGY STAR (worldwide), RoHS Directive
Operating Conditions Temperature: 59 to 86°F (15 to 30°C)
Humidity: 10 to 80%, non-condensing
Dimensions (WxDxH) Basket Open: 42 x 51 x 35″ (106.7 x 129.5 x 88.9 cm)
Basket Extended for Flatbed Stacking: 42 x 51 x 43″ (106.7 x 129.5 x 109.2 cm)
Weight 150 lb (68 kg) with stand
