MODEL GX-300 GX-400 GX-500 GX-640
Cutting method Media-movement method
Driving method Digital control servo motor Friction feed/Digital control servo motor
Maximum cutting area 29 x 984-1/8″
(737 x 24,998mm) 39 x 984-1/8″
(1000 x 24,998mm) 47 x 984-1/8″
(1195 x 24,998mm) Width: 65″ (1651 mm)
Acceptable media width 2 to 36″
(50 to 915mm) 3-1/2 to 46″
(90 to 1178mm) 3-1/2 to 54″
(90 to 1372mm) 5-1/16″ to 72.5″ (130 mm to 1842 mm)
Maximum cutting speed During cutting: 33ips (850mm/sec.) [in all directions]
During tool-up: 47 ips (1202mm/sec) [in 45º direction] During cutting: 33.5″/sec (850 mm/sec) (in all directions)
During tool-up: 47″/sec (1202 mm/sec)
Cutting force 20 to 350 gf 1 to 85 cm/sec (in increments of 1 cm/sec), 20 to 350 grams force (increments of 10 grams) >
Mechanical resolution 0.00049″/step (0.0125mm/step) 0.000137″/step (0.0035 mm/step)
Software resolution 0.00098″/step (0.025mm/step) 0.000984″/step (0.025 mm/step)
Distance accuracy Error of less than ± 0.2% of distance traveled, or 0.00039 (0.1mm), whichever is greater Error of less than 0.2% of distance traveled, or 0.00394″ (0.1 mm), which is greater
Repetition accuracy 0.1mm or less (excluding stretching/contraction of the material)
Range for assured repetition accuracy
For materials with a width exceeding 24″ (610mm): Length 157-7/16″ (4000mm) (GX-400/500 only)
For materials with a width of 24″ (610mm) or less: Length 314-15/16″ (8000mm) 0.004″ (0.1 mm) or less
Interface Serial (RS-232C compatible), USB (Rev. 1.1) Serial (RS-232C-compatible), USB (Rev 1.1)
Buffer size 8MB (2MB for re-plot buffer) 2 MB (buffer size: 8 MB)
Power supply AC 100V to 240V +/- 10% 50/60Hz 1.2A AC 100V to 240V =/- 10% 50/60Hz 1.1A AC 100V to 240V ±10% 50/60Hz 1.2A
Power consumption Approx. 95W Approx. 100WApprox. 100W
Acoustic noise level Cutting mode: under 62 dB (A) Standby Mode: under 40 dB (A) (According to ISO 7779)
Dimensions with stand 45-1/16(W) x 28-5/8(D) x 43-13/16″(H)
1144(W) x 727(D) x 1113mm (H) 55-3/8(W) x 28-5/8(D) x 43-13/16″(H)
1407(W) x 727(D) x 1113mm(H) 63-1/16(W) x 28-5/8(D) x 43-13/16(H)
1602(W) x 727(D) x 1113mm (H) 83-1/4 (W) x 28-5/8 (D) x 43-13/16 (H) in (2155 (W) x 727 (D) x 1113 (H) mm)
Weight with stand 97lb. (44 kg) 112.4lb. (51 kg) 121.2 lb. (55 kg) 141.1 lb (64 kg)
Operating temperature 41 to 104F (5 to 40C)
Operating humidity 35 to 80% (non-condensing)
Standard accessories Power cord, blade, blade holder, alignment tool, cable clamp, replacement blade for separating knife, Roland Software Package CD-ROM (CutStudio design software, plug-ins for CorelDraw 10/11/12 and Adobe Illustrator 9/10/CS), startup guide, user manual Power cord, blade holder (XD-CH2), pin, blade, blade (ZEC-U5022), alignment tool, cable clamp, replacement blade for sheet cutter, USB cable, Roland software CD-ROM, setup guide, user’s manual
